3D Design

---

I designed these cable brackets to help manage the cabling for an off-grid  solar power system./

When I fractured my index finger I had to wear a splint for 4 weeks. I found the splint uncomfortable as my finger got hot, it unnecessarily restricted motion, and the tape/glue caused my finger to get sticky. I needed to design a splint that was easy to take off but stayed on my finger when needed. I over-engineered the first design as it was sharp and rubbed. However, on my final design I included a lot more bevels and holes to keep it light and stop my finger from sweating. I 3D printed the designs flat and placed them in hot water so I could mold it to my finger.

I designed, printed and sold this Scout woggle to raise funds for the World Scout Jamboree in 2019 riainsg £250 towards by ticket.

My neighbour was going to throw away an old dog house. Instead, I asked if I could renovate it and use it for my dog.

 I took the internal measurements and made a new frame.

I reused the front and side walls to minimise wastage and made the kennel lower as the bottom had rotted

I used CAD to calculate how much timber I needed to buy.
